CTi Leading the Way with Profinet-Compliant SPE Cables

2026.09.14




As industrial communication evolves toward simpler, faster, and more efficient connectivity, we'd like to introduce how PROFINET-compliant Single Pair Ethernet (SPE) cables are shaping the next generation of industrial networks and how CTi is addressing these demands with advanced cable solutions.

What is Single Pair Ethernet (SPE), and why is it important?

Single Pair Ethernet (SPE) is an emerging technology in industrial communication that enables high-speed data transmission using just one pair of wires. Compared to traditional Ethernet cabling, SPE reduces size, weight, and overall system cost.
Additionally, SPE supports Power-over-Data Line (PoDL), allowing both data and power to be transmitted through a single cable. This significantly simplifies cabling infrastructure, especially in space-constrained and complex industrial environments.


Why PROFINET Compliance Matters?

PROFINET compliance ensures that Single Pair Ethernet (SPE) solutions meet the strict industrial requirements for performance, reliability, and interoperability.
Driven by PROFIBUS & PROFINET International (PI), this integration allows SPE technology to be seamlessly incorporated into existing PROFINET networks, providing standardized and reliable communication while advancing the vision of Industry 4.0 and smarter industrial automation.


What makes CTi's PROFINET-compliant SPE cables different?

CTi's PROFINET-compliant SPE cables are specifically engineered to exceed standard SPE performance.
Key advantages include:
  •        Enhanced flame retardancy for improved safety
  •        Heat shock resistance without cracking
  •        Tensile strength up to 50N
  •        Designed for high-flex and dynamic applications
These features ensure reliable performance even under the most demanding industrial conditions.


What SPE product solutions does CTi offer?

CTi provides a comprehensive SPE cable portfolio, including:
•        Standard SPE cables
•        High-flex SPE cables for dynamic applications
•        M8/M12 hybrid cable solutions

These options are ideal for use in industrial robots, moving machinery, and advanced automation systems.

See the comparison chart below for detailed specifications.

Standard SPE Cable: Features:
SF/TP Solid AWG18/1 PUR
SF/TP Solid AWG22/1 PUR
SF/TP Patch AWG22/7 PUR (Without Filler)
SF/TP Patch AWG26/7 PUR (Without Filler)		 ．Standard for IEC 61156-11/-12/-13
．Standard for IEEE 802.3bp / IEEE 802.3cg
．Flame Retardant to CMX
．Oil Resistant to UL 758 60℃
．Power over Data Line (PoDL) Support: Enables simultaneous power and data transmission.
High Flex Cable: Features:
SF/TP Patch AWG26/19 PUR ．Connectivity Distance: up to 40 meters
．Spec:
OP1:
-Drag chain: up to 5 million cycles
-Torsion: up to 5 million cycles
OP2:
-Torsion: up to 1 million cycles
Hybrid Cable: Features:
M8:1x2xAWG26(For Data) + 2xAWG18(For power)
M8:1x2xAWG22(For Data) + 2xAWG18(For power)
M12:1x2xAWG26(For Data) + 4xAWG16(For power)		 ． One device — One interface, direct data transmission and power supply
． Power supply of 200 W @ 24 V DC, 400 W @ 48 V DC and 400 W (2x) @ 60 V DC
． Resistance to all the harsh and industrial environments
SPE PROFINET Cable: Features:
Type A:
SF/TP PATCH AWG22/1 PVC
Type B:
SF/TP PATCH AWG22/7 PVC		 ．Crush test of the cable to IEC 62012-1
．Pressure test at high temperature for insulation and sheaths/ Heat shock test to IEC 60811
．Tensile performance of the cable to EN 50289-3-16

If you would like to learn more about our SPE solutions or discuss how they can support your current or future projects, please feel free to contact us. Our team will be happy to assist you and help you find the right solution for your application.

CTi Group is a professional cable OEM/ODM solution provider established in Taiwan for over 60 years. CTi Group has been dedicated to the integrity of high-frequency and high-speed cable industry for many years which provides customers with product design, development, and production solution by integrating outstanding tooling design, industrial automation, and procedure capability. CTi Group’s main products include LAN Cable, LAN patch cord, HDMI, USB, DP, Industrial and Medical cable, etc.
