Industrial Single Pair Ethernet ｜Hybrid Cable
Description：
Download file
-
Features
- - Transfer rates up to 1 Gbit/s at 600 MHz bandwidth
- Up to 40 m distance with 1 Gbit/s (1000BASE-T1)
- Easy power distribution by utilizing existing power infrastructures
- Power over separate wire pair up to 200 W @ 24 V DC and 400 W @ 48 V DC
- Power over separate wire pair up to 2 x 400 W @ 60 V DC (Only for AWG26 + AWG16 Hybrid Cable)
- Halogen-free
- Flame tested to IEC 60332-1
- UV resistance to IEC 60068-2-5
- Oil Resistant to UL 758
Applications
- - Automotive
- Process Industry
- Building Automation
- Sensor installation
- Lighting Systems
- - Transfer rates up to 1 Gbit/s at 600 MHz bandwidth
-
CTi Cable Code AWG
(Data)AWG
(Power)OD(mm) Construction Data Rate Standard Data Sheet No. GND2003 22 18 7.5 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0022 GNL2004 26 18 6.5 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0023 GNL2005 26 16 7.7 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0023
-
Features & Applications
Features
- - Transfer rates up to 1 Gbit/s at 600 MHz bandwidth
- Up to 40 m distance with 1 Gbit/s (1000BASE-T1)
- Easy power distribution by utilizing existing power infrastructures
- Power over separate wire pair up to 200 W @ 24 V DC and 400 W @ 48 V DC
- Power over separate wire pair up to 2 x 400 W @ 60 V DC (Only for AWG26 + AWG16 Hybrid Cable)
- Halogen-free
- Flame tested to IEC 60332-1
- UV resistance to IEC 60068-2-5
- Oil Resistant to UL 758
Applications
- - Automotive
- Process Industry
- Building Automation
- Sensor installation
- Lighting Systems
- - Transfer rates up to 1 Gbit/s at 600 MHz bandwidth
-
Specifications
CTi Cable Code AWG
(Data)AWG
(Power)OD(mm) Construction Data Rate Standard Data Sheet No. GND2003 22 18 7.5 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0022 GNL2004 26 18 6.5 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0023 GNL2005 26 16 7.7 +/- 0.3 SF/TP 1Gbps IEC 61156-12 DT0023
