CPR-Compliant Ethernet Cable

CTi’s CPR-compliant Ethernet cable series is designed to meet the fire safety requirements of the European market for permanently installed communication cables in buildings. Complying with EN 50575 under EU Regulation 305/2011, this series is classified by Euroclass standards (B2ca, Cca, Dca, Eca) and tested under recognized flame, smoke, and toxicity performance standards.These cables are widely used in commercial buildings, infrastructure, and residential environments where fire protection and compliance with EU construction codes are essential. Available in multiple categories (Cat.5e / Cat.6 / Cat.6A / Cat.7), constructions (U/UTP, U/FTP, F/UTP, F/FTP, S/FTP), and jacket types(LSZH, FRLSZH or PVC), they deliver both high-speed transmission and certified flame resistance.

Applications

B2ca

Critical Infrastructure
(Data Centers, Control Rooms)

B2ca / Cca

Public Buildings
(Hospitals, Airports, Schools)

Cca / Dca

Commercial Buildings
(Offices, Hotels)

Dca / Eca

Residential (Apartments)

Eca

Basic Indoor Cabling

Product List

左右滑動看表格
Standard Category Construction CTi Cable Code Conductor AWG OD(mm) OD(inch) Outer Jacket
EN50399 Eca Cat.5e Cable U/UTP GAL2009 Solid 24 4.9 +/- 0.5 0.19 +/- 0.02" LSZH
Cat.6 Cable U/UTP (with Crossfiller) GBL2009 Solid 23 5.7 +/- 0.5 0.22 +/- 0.02" LSZH
Cat.6 Cable U/UTP (with Crossfiller) GAR2009 Solid 24 5.4 +/- 0.5 0.21 +/- 0.02" LSZH
Cat.6 Cable U/FTP GBC2009 Solid 23 6.4 +/- 1 0.25 +/- 0.04" LSZH
Cat.6 Cable  F/UTP GBH2009 Solid 23 7.2 +/- 0.5 0.29 +/- 0.02" LSZH
Cat.6 Cable  F/UTP GBH2021 Solid 24 6.8 +/- 0.5 0.27 +/- 0.02" LSZH
Cat.6 Cable  F/FTP GBC2036 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.6 Cable  F/FTP GBC2037 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6 Cable  S/FTP GBC2024 Solid 23 7.1 +/- 0.5 0.28+/- 0.02" LSZH
Cat.6 Cable  S/FTP GBC2039 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
EN50399 Eca
EN50399 Dca		 Cat.6 Cable  F/FTP｜Dual GBC2041 Solid 23 6.4x13.1 +/- 0.5 - LSZH
EN50399 Eca Cat.6A Cable U/FTP GBK2009 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.6A Cable U/FTP GBK2045 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable F/UTP GBR2018 Solid 23 7.4 +/- 0.5 0.29 +/- 0.02" PVC
Cat.6A Cable F/UTP GBR2022 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable F/UTP GBR2009 Solid 24 6.8 +/- 0.5 0.27 +/- 0.02" LSZH
Cat.6A Cable F/FTP GBK2022 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.6A Cable F/FTP GBK2042 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable S/FTP GBK2035 Solid 23 7.1 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable S/FTP GBK2040 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.7 Cable F/FTP GBS2009 Solid 23 6.6 +/- 0.5 0.26 +/- 0.02" LSZH
Cat.7 Cable S/FTP GBJ2009 Solid 23 7.1 +/- 0.5 0.28 +/- 0.02" LSZH
EN50399 Dca Cat.6 Cable U/UTP (with Crossfiller) GBL2010 Solid 23 5.7 +/- 0.5 0.22 +/- 0.02" LSZH
Cat.6 Cable U/UTP (with Crossfiller) GAR2010 Solid 24 5.4+/- 0.5 0.21 +/- 0.02" LSZH
Cat.6 Cable  F/UTP GBH2010 Solid 23 7.2 +/- 0.5 0.29 +/- 0.02" LSZH
Cat.6 Cable  F/UTP GBH2022 Solid 24 6.8 +/- 0.5 0.27 +/- 0.02" LSZH
Cat.6 Cable  S/FTP GBC2025 Solid 23 7.1+/- 0.5 0.28 +/- 0.02" LSZH
Cat.6 Cable  S/FTP GBC2040 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6 Cable  U/UTP｜Dual GAR2028 Solid 24 5.4x11.1 +/- 0.5 - LSZH
Cat.6 Cable  F/FTP｜Dual GBC2042 Solid 23 6.4x13.1 +/- 0.5 - LSZH
Cat.6A Cable U/UTP GBQ2022 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable U/FTP GBK2010 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.6A Cable U/FTP GBK2049 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable F/UTP GBR2023 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable F/UTP GBR2010 Solid 24 6.8 +/- 0.5 0.27 +/- 0.02" LSZH
Cat.6A Cable F/FTP GBK2023 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.6A Cable F/FTP GBK2043 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable S/FTP GBK2036 Solid 23 7.1 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.6A Cable S/FTP GBK2041 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" LSZH
Cat.7 Cable F/FTP GBS2010 Solid 23 6.6 +/- 0.5 0.26 +/- 0.02" LSZH
Cat.7 Cable S/FTP GBJ2010 Solid 23 7.1 +/- 0.5 0.28 +/- 0.02" LSZH
EN50399 Cca Cat.6 Cable U/UTP (with Crossfiller) GBL2011 Solid 23 6.0 +/- 0.5 0.24 +/- 0.02" FRLSZH
Cat.6 Cable U/UTP (with Crossfiller) GAR2011 Solid 24 5.8 +/- 0.5 0.23 +/- 0.02" FRLSZH
Cat.6 Cable  F/UTP GBH2011 Solid 23 7.3 +/- 0.5 0.29 +/- 0.02" FRLSZH
Cat.6 Cable  U/UTP｜Dual GAR2029 Solid 24 5.8x11.9 +/- 0.5 - LSZH
Cat.6A Cable U/UTP GBQ2023 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" FRLSZH
Cat.6A Cable U/FTP GBK2011 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" FRLSZH
Cat.6A Cable F/UTP GBR2024 Solid 23 7.3 +/- 0.5 0.29 +/- 0.02" FRLSZH
Cat.6A Cable F/FTP GBK2024 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" FRLSZH
Cat.6A Cable S/FTP GBK2037 Solid 23 7.1 +/- 0.5 0.28 +/- 0.02" FRLSZH
Cat.6A Cable F/FTP｜Dual GBK2051 Solid 23 6.4x13.1 +/- 0.5 - LSZH
Cat.7 Cable F/FTP GBS2011 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" LSZH
Cat.7 Cable S/FTP GBJ2011 Solid 23 7.0 +/- 0.5 0.28 +/- 0.02" LSZH
EN50399 B2ca Cat.6 Cable U/UTP (with Crossfiller) GBL2012 Solid 23 6.0 +/- 0.5 0.24 +/- 0.02" FRLSZH
Cat.6 Cable U/UTP (with Crossfiller) GAR2012 Solid 24 5.8 +/- 0.5 0.23 +/- 0.02" FRLSZH
Cat.6 Cable  F/UTP GBH2012 Solid 23 7.3 +/- 0.5 0.29 +/- 0.02" FRLSZH
Cat.6A Cable U/UTP GBQ2025 Solid 23 7.2 +/- 0.5 0.28 +/- 0.02" FRLSZH
Cat.6A Cable U/FTP GBK2012 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" FRLSZH
Cat.6A Cable F/UTP GBR2025 Solid 23 7.3 +/- 0.5 0.29 +/- 0.02" FRLSZH
Cat.6A Cable F/FTP GBK2025 Solid 23 6.4 +/- 0.5 0.25 +/- 0.02" FRLSZH

For more information, please don't hesitate to contact us with any questions.
